— 6 —
2-2. On line
(1) Direct connection to P/C
[Cable]
1) Wiring diagram (A) A SYNC.
2) Parts list
No.
Code Number
Part
Specification
1
3612 0762
DIN 13P PLUG
TCP9361-71-111
2
3513 1019
Junction shell
DB-C2-J9
3
3510 2043
Shell connector
DB-25S
4
Cable
PLGW-3456-01A
PIN
SINGNAL
2S
D
3R
D
4R
S
5C
S
6D
R
7S
G
8C
D
20
ER
SIGNAL
PIN
GND
1
ER
3
SD
4
RS
5
RD
7
CS
8
CD
9
DR
10
CI
13
PC-DOS
Personal
Computer
ECR
Cable length = Max. 15m
7
9
Table of Contents
Table of Contents
2
In/On-Line Board I/O
3
To Install the I/O-Pb-11
3
Interface
5
C-In Line (ECR to ECR)
5
On Line
8
Circuit Explanations
10
Address Selection
10
Scale Buffer Circuit
11
On Line Circuit (RS-232C)
12
C-In Line Circuit
14
Diagnostic Operations
17
To Start the Diagnostic Operation
17
Check Items for I/O-PB-11
18
Operations
18
Error Code List
26
IC Data
29
Parts List
32
Pcb Layout
34
Circuit Diagram
35
