— 1 —
SPECIFICATIONS
GENERAL
Keyboard: 88 piano keys (with touch response)
Polyphony: 32 notes, maximum
Tones: 11; with layer, split
Digital Effects: Reverb (4 types), Chorus (4 types), DSP, Brilliance
Metronome: • Time Signatures: 0, 2, 3, 4, 5, 6
• Tempo Range: 30 to 255
Music Library: • Number of Tunes: 60
• Tune Volume: Adjustable
• Demo: Sequential looping of all 60 preset tunes
• Part On/Off: Left hand, right hand
Song Memory: • Operations: Real-time recording, playback
• Capacity: Approximately 10,000 notes (2 tracks total)
• Memory Backup: Built-in lithium battery (Battery Life: 5 years)
Pedals: Damper, Soft, Sostenuto
Other Functions: • Touch: 3 types, off
• Transpose: 1 octave (F
to C to F)
• Tuning: A4 = 440.0Hz ±50 cents (adjustable)
MIDI: 16 multi-timbre receive
Input/Output: • Headphones: Stereo standard jacks
2
Output Impedance: 170.
Output Voltage: 5.5V (RMS) MAX
• Power: 12V DC
• MIDI (OUT) (IN)
• Pedal connector
Speakers: 12cm 2 (Output: 8.0W + 8.0W)
Power Supply: AC Adaptor: AD-12
Power Consumption: 12V
18W
Dimensions: Digital piano + stand: 136.9 30.0 78.9 cm (53
15
/
16
11
13
/
16
31
1
/
16
inch)
Weight: Digital piano + stand: Approximately 32.5 kg (71.6 lbs)
ELECTRICAL
Load condition
Current drain with 12 V DC:
Speaker: 6 . Real Load
Volume: maximum
Tone: Strings
Touch: MAX mode
Keys: A0 - D5, 32poly
Consumption Current 1450 mA ± 20 %
Consumption Current at idle 230 mA ± 20 %
Speaker output level (Vrms with 6 . load each channel):
Tone: TEST MODE (Sin wave MAX L and MAX R)
L ch: 3000 mV ± 20 %
R ch: 3000 mV ± 20 %
Phone output level (Vrms with 32 . load each channel):
Tone: TEST MODE (Sin wave MAX)
L ch: 300 mV ± 20 %
R ch: 300 mV ± 20 %
