— 6 —
DISASSEMBLY
1. Remove 14 screws and then the lower panel.
2. Remove the T-BRD-UNIT.
■ Removing the PCBs (M404-MDA1, M406-CNA4, M404-PSA1).
3. Remove 13 screws.
3. Remove 4 screws.
T-BRD-UNIT
