– 42 –
SE-S400/SE-S800/PCR-T500/PCR-T520/SE-C450
SE-S3000/SE-S900/PCR-T2300/PCR-T2400/SE-C3500
7-4. PARTS LIST
1 SE-S400_SR
2 SE-S400_BK
3 PCR-T500
4 PCR-T520
5 SE-C450
6 SE-S3000_SR
7 SE-S3000_BK
8 PCR-T2300
9 PCR-T2400
10 SE-C3500
11 SE-S800
12 SE-S900
123456789101112
FINAL-ASS
Y
1 10421864 PULLY/WIND RJE503538-001V02 1 1 1 1 1 1 1 1 1111A
2 10445632 SPOOL/PAPER RJE504072-001V01 1 1 1 1 1 1 1 1 1111A
3 10452933 COVER/CONNECTOR RJE502339-005V04 1 1 1 1 1 1 1 1 1111C
4 10319830 COVER/BATTERY RJE502601-001V02 1 1 1 1 1 1 1 1 1111C
5 10452946 COVER/PRINTER RJE502345-015V02 1 1 C
5 10452949 COVER/PRINTER RJE502345-016V02 1 1 1 1 C
5 10452956 COVER/PRINTER RJE502345-017V02 1 1 C
5 10452958 COVER/PRINTER RJE502345-018V02 1 1 1 1 C
6 10452947 PLATE/DISPLAY RJE504100-001V01 1 C
6 10452950 PLATE/DISPLAY RJE504100-002V01 1 C
6 10452953 PLATE/DISPLAY RJE504100-003V01 1 C
6 10454353 PLATE/DISPLAY RJE504100-004V02 1 C
6 10452955 PLATE/DISPLAY RJE504100-009V01 1 C
6 10452957 PLATE/DISPLAY RJE504100-005V01 1 C
6 10452960 PLATE/DISPLAY RJE504100-006V01 1 C
6 10452959 PLATE/DISPLAY RJE504100-007V01 1 C
6 10452961 PLATE/DISPLAY RJE504100-008V01 1 C
6 10452963 PLATE/DISPLAY RJE504100-010V01 1 C
6 10481473 PLATE/DISPLAY RJE504100-011V02 1C
6 10484375 PLATE/DISPLAY RJE504100-012V02 1C
7 10284497 W-TAPE/65x8 RJE502542-002V01 2 2 2 2 2 2 2 2 2222X
8 10254924 KEY SET/MODE SW RJE500074*002V03 1 1 1 1 1 1 1 1 1111C
S1 SCREW S-BDPT-3X8ZC 333333333333X
B-CASE-ASS
Y
9 10370496 CABLE/FFC JOINER E441341-014V03 1 1 1 1 1 1 1 1 1111B
10 10294860 MOTOR-ASSY RJE502538*002V01 1 1 1 1 1 1 1 1 1111B
10-1 10234746 RUBBER/WINDER RJE502008-001V01 1 1 1 1 1 1 1 1 1111C
10-2 10282326 CONNECTOR ASSY/MOTOR RJE502393*001V02 1 1 1 1 1 1 1 1 1111C
10-3 10264935 MOTOR WRF-370C-13380 1 1 1 1 1 1 1 1 1111B
11 10452921 PS-UNIT EHF0800400Y1BA 1 1 1 1 1 1 1 1 1111C
12 10448032 PRINTER/THERMAL LTP01-245-02 1 1 1 1 1 2 2 2 2212A
13 10359207 PLATEN ARM/J RJE502343-001V03 1 1 1 1 1 1 1 1 1111C
RParts NameN Code No. SpecificationItem
Q'TY
