When there is a serial connection between the projector and a computer, you can control the projector

using RS-232C commands sent from the computer.

To establish a serial connection between the projector and a

computer

Connect the projector and computer as shown in the illustration below.

XJ-A Series

XJ-M Series

Projector RS-232C Control

Projector

Computer

Serial port

YK-60 special cable (available separately)

Projector

Commercially available serial cable (cross)

Computer

Serial port (RS-232C)

D-Sub 9-pin (female)

Serial port*

D-Sub 9-pin (female)
