SAFETY
Front View
FIG. 13: Front View
(1) 501291D1 Jump Start Cables.
The safety sign is located on the frame rail on the right
side of the tractor.
Improper jumper cable connections can cause explosion
resulting in personal injury.When using jumper cables,
always connect positive (+) cable, from external source, to
positive (+) jump start post and negative (-) cable, from
external source, to engine block or frame.
(2) 501287D1 Electrical Shock Hazard.
The safety sign is located on the frame rail on the right
side of the tractor.
Electric shock from the voltage system can cause serious
injury or death. For proper jump start procedures please
refer to your Operation and Maintenance manual.
(3) 501258D1 Starter Bypass.
The
safety sign is located on the starter motor on the right
side of the tractor.
Start engine from operator's seat only. Personal injury
could result from inadvertent machine operation if neutral
start switch or starter solenoid is bypassed. When using
jump start cables, always connect positive cable to
positive jump start post and the negative cable to the
engine or frame. Improper jump start cable connections
can cause an explosion, resulting in personal injury.
FIG. 13
3
501258D1 1
2
501287D1 1
1
501287D1
501291D1
ch-0025
501258D1
