Q (High): Turn the thumbwheel to this position to
supply the most amount of heat to the rear-seating area.
c (Medium): Turn the thumbwheel to this position
to supply half the amount of heat to the rear-seating
area.
R (Low): Turn the thumbwheel to this position to
supply the least amount of heat to the rear-seating area.
9 (Off): Turn the thumbwheel to this position to
turn the rear heating system off.
Rear Air Conditioning and Heating
System
Your vehicle may have a rear heating and
air-conditioning system. This system regulates the
temperature, the fan speed and the air delivery for the
rear-seat passengers only. It also works with the
main climate-control system in your vehicle.
Use this control panel when you would like to maintain
a separate temperature setting. Adjust the direction
of the airflow or adjust the fan speed for the rear seat
passenger(s).
If your vehicle has a 135 inch (343 cm) wheelbase, a
rear control panel for this system is located in the
second row behind the driver in the rear of your vehicle.
Front Climate Control Panel
Rear Climate Control Panel
3-23
