10-46 Vehicle Care
Center High-Mounted
Stoplamp (CHMSL) and
Cargo Lamp
To replace one of these bulbs:
1. Remove the two screws and lift
off the lamp assembly.
A. Cargo Lamp
B. Center High-Mounted
Stoplamp (CHMSL) Bulb
2. On the reverse side of the lamp
assembly, remove the bulb
socket by turning it one quarter
turn counterclockwise and pull it
straight out.
3. Remove the bulb by pulling it
straight out of the socket.
4. Install the bulb by pushing the
bulb straight into the socket.
5. Install the bulb socket into the
lamp asembly by turning it
one quarter turn clockwise.
6. Reinstall the lamp assembly and
tighten the screws.
License Plate Lamp
To replace one of these bulbs:
1. Reach under the rear bumper for
the bulb socket.
2. Turn the bulb socket
counterclockwise and pull the
bulb socket out of the lamp
assembly.
3. Pull the old bulb straight out
from the bulb socket.
4. Install the new bulb.
5. Reverse Steps 1 and 2 to
reinstall the bulb socket.
