Vehicle Care 9-33
License Plate Lamp
To replace one of these bulbs:
1. Open the liftgate partway. See
Liftgate (Manual)
on page 1‑8
or Liftgate (Power)
on
page 1‑8
for more information.
Passenger side shown, driver side
similar
2. Push the left end of the lamp
assembly towards the right.
3. Pull the lamp assembly down to
remove from liftgate.
A. Bulb Socket
B. Bulb
C. Lamp Assembly
4. Turn the bulb socket (A)
counterclockwise to remove from
lamp assembly (C).
5. Pull the bulb (B) straight out of
the bulb socket.
6. Push the replacement bulb
straight into the bulb socket and
turn the bulb socket clockwise to
install into lamp assembly.
7. Turn the lamp assembly into the
liftgate engaging the clip side
first.
8. Push on the lamp side opposite
the clip until the lamp assembly
snaps into place.
