Vehicle Care 9-37
Midi Fuse Usage
53
Electric Power
Steering
Micro
Relays
Usage
54 Rear Defogger
55 Cooling Fan Low
56
Head Lamp
High Beam
57 Cooling Fan Control
58
Wiper On/Off
Control
59
Air Conditioning
Compressor
60 Wiper Speed
61 Fog Lamp
62 Engine Control
63 Starter
64 Run/Crank
Mini Relays Usage
65 Cooling Fan High
66 Brake Booster
Instrument Panel Fuse
Block
The instrument panel fuse block
is located on the passenger
side panel of the center console.
To access the fuses, open the fuse
panel door from the passenger side
by pulling it out.
To reinstall the door, insert the tabs
on the bottom of the door into the
console first, then push the door
back into its original location.
The vehicle may not be equipped
with all of the fuses and relays
shown.
