Removing the Bench Seat
To remove the full bench seat, do the following:
1. Open the rear doors and enter the rear of the
vehicle.
2. Fold the seatback
forward onto the seat
cushion by using
the lever labeled 1.
The seat cannot
be removed unless the
seatback is folded.
3. To unlatch the seat
from the floor, pull up
on the release lever
labeled 2, located at the
rear of the seat, and lift
the rear of the seat up
off the floor.
4. Squeeze the release lever, located in the lower
middle to unlatch the seat from the floor while
pulling the seat out.
5. While holding the rear of the seat up, roll the seat
out of the vehicle.
1-19
