CHAIN BREAK DELAY
The motion delay is used to compensate for starting delays caused by clutch slippage.
1. The motion delay is factory set at 999. Decrease the delay until motion fault occur.
2. Slowly increase the delay until motion faults are eliminated.
3. Add some delay to allow for clutch wear.
The motion delay is only used when the clutch is engaged. It delays before the low SPMs are checked to allow for
clutch slippage. The motion delay works in conjunction with the low speed limit. When the clutch is engaged the
press speed must reach the low speed limit before the motion delay times out.
SPM - Strokes Per Minute
^MDLY >D999
HIGH and LOW SPEED LIMITS
Monitors the press SPM during normal operation.
1. Program the Low speed for the minimum allowable speed of the press in SPM during normal operation.
2. Program the High speed for the maximum allowable speed of the press in SPM during normal operation.
Durring normal operation of the press if the speed should fall outside the programmed limits a Motion Fault mes-
sage will be displayed and the fault output will de-energize. The fault is cleared by pressing RESET. See MOTION
FAULT under fault messages for a complete explanation of possible motion fault problems.
^MDET >L000-H999
7 7
