Cisco 8811 User Manual

Autodials your voice messaging system (varies by system).Messages button17
Returns to the previous screen or menu.Back button18
Phone handset.Handset19
Cisco IP Phone 8845
The following sections describe attributes of the Cisco IP Phone 8845.
Phone Connections
Connect your phone to the corporate IP telephony network, using the following diagram.
Draft comment: Design Team: Please provide graphic.
Access port (10/100/1000 PC) connection.5DC adaptor port (DC48V).1
Auxiliary port.6AC-to-DC power supply (optional).2
Handset connection.7AC power wall plug (optional).3
Analog headset connection (optional).8Network port (10/100/1000 SW) connection.
IEEE 802.3at power enabled.
4
Camera pin holes (for Cisco Unified Video
Camera)
9
The Cisco IP Phone 8845 does not support the Cisco IP Phone 8800 Key Expansion Module.Note
Cisco IP Phone 8811, 8841, 8845, 8851, 8851NR, 8861, and 8865 User Guide for Cisco Unified Communications Manager
11.0
11
Getting Started
Cisco IP Phone 8845
