Cisco ASR 1000 Series Quick Start Guide

26
Router#show platform
Chassis type: ASR1002-X
Slot Type State Insert time (ago)
--------- ------------------- --------------------- -----------------
0 ASR1002-X ok 17:17:43
0/0 6XGE-BUILT-IN ok 17:16:59
R0 ASR1002-X ok 17:17:43
R0/0 ok, active 17:17:43
R0/1 ok, standby 17:16:30
F0 ASR1002-X ok, active 17:17:43
P0 ASR1002-PWR-AC ok 17:17:20
P1 ASR1002-PWR-AC ps, fail 17:17:19
Slot CPLD Version Firmware Version
--------- ------------------- ---------------------------------------
0 11082401 15.2(4r)S
R0 11082401 15.2(4r)S
F0 11082401 15.2(4r)S
If the LEDs indicate a power problem or the power supply state is ps,fail, then contact a customer service representatives for
assistance or additional instructions.
Start the Cisco ASR 1002-X Router
After installing your Cisco ASR 1002-X Router and connecting cables, start the router as follows.
Check the following conditions before you start the Cisco ASR 1002-X Router:
• The Cisco ASR 1002-X Router has one slot for FP0 with three subslots for SPAs, subslots 1, 2, and 3. Make certain that
each shared port adapter is firmly seated in its subslot and its captive screws are securely tightened.
• The Cisco ASR1000-ESP5 or ASR1000-ESP10 forwarding processor in the Cisco ASR 1002-X router is inserted in slot F0,
is firmly seated in its slot, and its captive screws are securely tightened.
• All network interface cables are connected.
• The console terminal is turned on.
Step 1 Turn on power. The green OK LED on the power supply turns on. (Both power supplies are required in the Cisco
ASR 1002-X Router.)
Step 2 Listen for the fans; you should immediately hear them operating.
Step 3 During the boot process, observe the system LEDs. The power LED should be green. The STATUS LED lights yellow
to indicate booting and then green when Cisco IOS is running.
Table 3 provides information about the LEDs as the system starts.
Table 3 Cisco ASR 1002-X Router LED Activity
LED Label LED Color In the Power Up State -Behavior Description
PWR Power Solid green All power requirements are within specification.
Off The router is in standby mode.
STAT System status Solid green Cisco IOS has successfully booted.
Yellow BOOT ROM has successfully loaded.
Red System failure.
CRIT Critical Solid red Critical alarm indicator. On at power up
