Note: Logging of all traffic hitting the default deny acl can generate a large number of logs, and
a determination should be made whether it is necessary prior to entering this at the end of all
access lists.
To apply the acls to the interfaces:
TOE-common-criteria(config)# interface GigabitEthernet0/0
TOE-common-criteria(config-if)# ip access-group 199 in
TOE-common-criteria(config)# interface GigabitEthernet0/1
TOE-common-criteria(config-if)# ip access-group 100 in
Additional information on creation of packet filtering and VPN information flow policies is
given in Section 4.6.4 below.
The following ACL in the running-configuration can be used to block unknown protocols
(Explicitly permitting and logging specific IPv6 protocols then explicitly denying any other IPv6
packet) -
permit 1 <source> <destination> log
permit 2 <source> <destination> log
permit 3 <source> <destination> log
permit 4 <source> <destination> log
permit 5 <source> <destination> log
permit tcp <source> <destination> log
permit 7 <source> <destination> log
permit 8 <source> <destination> log
!…. continue the ACL entries to include all IPv6 protocol numbers listed in the PP.
deny ipv6 <source> <destination> log
3.3.6 Routing Protocols
The routing protocols are used to maintain routing tables. The routing tables can also be
configured and maintained manually. Refer to the applicable sections in [3] for configuration of
the routing protocols.
3.3.7 MACSEC and MKA Configuration
The detailed steps to configure MKA, configure MACsec and MKA on interfaces are listed in
[24] - http://www.cisco.com/c/en/us/td/docs/ios-xml/ios/macsec/configuration/xe-16/macsec-xe-
16-book/wan-macsec-mka-support-enhance.html#d74e990a1635
Note: For 256-bit encryption, the key-string length will be 64-characters. For 128-bit encryption,
the key-string length will be 32 characters.

Cisco ASR 1001 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	-
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB ports quantity	1
Ethernet LAN (RJ-45) ports	4
VPN tunnels quantity	8000
Product color	Gray
Rack capacity	1U
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	8192 MB
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	11350 g
