Procedure
Step 1 Remove the SFC card from slot FC0. Follow the procedure explained in the topic Removing and Replacing
Cards from the Chassis, on page 245.
Alarms are raised when fabric cards are removed and when the system has a combination of old and new
generation fabric cards. These alarms clear when all the fabric cards are replaced.
Step 2 Insert A99-SFC3-T/A99-SFC3-S card in slot FC0. Follow the procedure explained in the topic Replacing
Cards in the Chassis, on page 247
Step 3 Wait for A99-SFC3-T/A99-SFC3-S card to come online. Verify the card state is OPERATIONAL using the
show platform command.
Step 4 Repeat Step1 through Step 3 for migrating remaining FCs from slot FC1 to slot FC4.
Example:
Router# show platform
Node Type State Config state
--------------------------------------------------------------------------------
0/RSP0/CPU0 A9K-RSP5-TR(Standby) IOS XR RUN NSHUT
0/RSP1/CPU0 A9K-RSP5-TR(Active) IOS XR RUN NSHUT
0/FT0 ASR-9910-FAN OPERATIONAL NSHUT
0/FT1 ASR-9910-FAN OPERATIONAL NSHUT
0/1/CPU0 A9K-8X100GE-TR IOS XR RUN NSHUT
0/FC0 A99-SFC3-S OPERATIONAL NSHUT
0/FC1 A99-SFC3-S OPERATIONAL NSHUT
0/FC2 A99-SFC3-S OPERATIONAL NSHUT
0/FC3 A99-SFC3-S OPERATIONAL NSHUT
0/FC4 A99-SFC3-S OPERATIONAL NSHUT
0/PT0 A9K-AC-PEM-V3 OPERATIONAL NSHUT
0/PT1 A9K-AC-PEM-V3 OPERATIONAL NSHUT
Use the admin show alarm and show pfm location all commands to verify no additonal alarms are raised
after replacing all the FCs.
Removing a Chassis from the Equipment Rack
Follow these steps to remove the chassis and its components from the equipment rack:
Procedure
Step 1 Power off the router (see Powering Off the Router, on page 223).
You must use two people to remove the chassis from the equipment rack safely. An empty chassis
can weigh up to approximately 300 pounds (136 kg).
Caution
Step 2 Power off the circuit breakers to the power supplies.
Step 3 Disconnect the power from the power modules on the rear of the chassis.
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
263
Replacing Cisco ASR 9000 Series Router Components
Removing a Chassis from the Equipment Rack
