Cisco DPC3216 User Manual

Special Conditions
OL-31573-01 25
Special Conditions
The following chart describes the appearance of the cable modem front panel LED
status indicators during special conditions to show when you have been denied
network access.
Front Panel LED Status Indicators During Special Conditions
Front Panel Indicator
Network Access Denied
1
POWER
On
2
DS
Flashes in unison with the US indicator
(twice per second)
3
US
Flashes in unison with the DS indicator
(twice per second)
4
ONLINE
Off
5
ETHERNET
Off - No CPE connected
On - CPE connected
Flash - CPE data activity
6
TEL 1
Off
7
TEL 2
Off
8
BATTERY
On

Cisco DPC3216 Specifications

General

Brand	Cisco
Model	DPC3216
Category	Modem
Language	English
