13
Switch Installation
Connecting to Power
Crimping tool (such as Thomas & Bett part number WT4000, ERG-2001, or equivalent).
10-gauge copper ground wire.
For DC power connections, use UL- and CSA-rated, style 1007 or 1569 twisted-pair copper appliance wiring
material (AWM) wire.
Wire-stripping tools for stripping 10- and 18-gauge wires.
A number-2 Phillips screwdriver.
A flat-blade screwdriver.
Supported Power Supplies
Installing the Power Supply on a DIN Rail, Wall, or Rack Adapter
You install the power converter on a DIN rail, wall, or rack as you would a switch module.
Warning: This equipment is supplied as “open type” equipment. It must be mounted within an enclosure that is
suitably designed for those specific environmental conditions that will be present and appropriately designed to
prevent personal injury resulting from accessibility to live parts. The interior of the enclosure must be accessible
only by the use of a tool.
The enclosure must meet IP 54 or NEMA type 4 minimum enclosure rating standards. Statement 1063
Caution: To prevent the switch assemble from overheating, there must be sufficient spacings as explained under
Installation Guidelines, page 11, between any other switch assembly.
Grounding the Switch
Make sure to follow any grounding requirements at your site.
Table 1 Supported Power Supplies
PWR-IE65W-
PC-DC
PWR-IE65W-
PC-AC
PWR-IE170W-
PC-DC
PWR-IE170W-
PC-AC
PWR-IE50W-
AC-IEC
PWR-IE50W-
AC
Current
DC-DC AC-DC DC-DC AC-DC AC-DC AC-DC
Input
18-60 VDC/4.3
Amp
110/220 VAC and
88-300 VDC
10.8-60 VDC/23
Amp
110/220 VAC and
88-300 VDC/2.1
Amp
110/220 VAC 110/220VAC and
88-300 VDC
Output
54VDC/1.2 Amp 54VDC/1.2 Amp 54VDC/3.15 Amp 54VDC/3.15 Amp 24VDC/2.1Amp 24 VDC / 2.1Amp
Dimensions
5.9 in H x 2.1 in. W
x 4.9 in. D
5.9 in. H x
2.1 in. W x
4.9 in. D
5.93 in (149.8 mm)
H x 4.47 in. (113.5
mm) W x
5.7 in. (144.7 mm)
D
5.93 in. (150.6mm
) H x
3.72 in. (94.5mm)
W x
5.6 in. (142.2mm)
D
5.8in.H x 2in.W
x 4.4 in. D
5.8in.H x 2in.W
x 4.4 in. D
Usage
Designed for up to
25W of POE load
Designed for up to
25W of POE load
Designed for up to
8 POE ports or
123W of POE
power.
Designed for up to
8 POE ports or
123W of POE
power.
No POE support No POE support
