Cisco IE 3010 Switch Getting Started Guide
10
Cisco IE 3010 Switch Getting Started Guide
78-19582-02
3. Configure the PC terminal emulation software for 9600 baud, 8 data bits, no
parity, 1 stop bit, and no flow control.
4. Use the CLI to enter configuration commands. See the software configuration
guide and the command reference for more information.
Note You cannot use the switch RJ-45 console port and the switch USB console
port at the same time to access the CLI.
Installing the Switch
This section covers 19-inch rack-mounting, wiring procedures, and switch port
connections. The illustrations show the Cisco IE-3010-24TC switch. You can
install and connect other Cisco IE 3010 switches as shown in these examples. For
alternate mounting procedures, such as installing the switch on a wall and for
additional cabling information, see the switch hardware installation guide.
Equipment That You Need
• Ratcheting torque flathead screwdriver that exerts up to 15-inch pound (in-lb)
of torque
• Ring, spade, or flanged spade terminal (terminals should be insulated):
– Ring terminal (such as Tyco part number 2-34158-1 for 16–14 AWG, or
2-34852-1 for 12–10 AWG wire)
– Spade terminal (such as Tyco part number 54367-2 for 16–14 AWG wire)
– Flanged spade terminal (such as Tyco part number 2-324165-1 for 16–14
AWG wire, or 1-324581-1 for 12–10 AWG wire)
