Cisco ISA 3000 Industrial Security Appliance Hardware Installation Guide
Chapter 2 Installing the Cisco ISA 3000 Industrial Security Appliance
Installing the Cisco ISA 3000
Step 4 Remove the device from the DIN rail.
Mounting the ISA 3000 in a Rack
The ISA 3000 can be mounted in a 19" cabinet/rack with the optional kit part number
STK-RACKMNT-2955. This kit includes a bracket and mounting screws, see Figure 2-2.
Figure 2-2 Mounting Bracket
To install the ISA 3000 in a cabinet or rack, perform the following steps:
Step 1 Install the bracket in the cabinet or rack using the 4 front screws included in the kit. Place the screws
through the mounting holes (#1).
Step 2 Attach The device to the DIN rail built into the mounting bracket (#2) in the same manner as described
in Installing a DIN Rail.
