Connections established 1; dropped 0
Local host: 13.13.13.1, Local port: 35018, IF Handle: 0x00000000
Foreign host: 20.20.20.1, Foreign port: 179
Last reset 00:00:00
• Verify if all the IP addresses are learnt on PE1 from PE2:
Router-PE1#show bgp vpnv4 unicast
BGP router identifier 13.13.13.1, local AS number 2001
BGP generic scan interval 60 secs
Non-stop routing is enabled
BGP table state: Active
Table ID: 0x0 RD version: 0
BGP main routing table version 798487
BGP NSR Initial initsync version 15151 (Reached)
BGP NSR/ISSU Sync-Group versions 0/0
BGP scan interval 60 secs
Status codes: s suppressed, d damped, h history, * valid, > best
i - internal, r RIB-failure, S stale, N Nexthop-discard
Origin codes: i - IGP, e - EGP, ? - incomplete
Network Next Hop Metric LocPrf Weight Path
Route Distinguisher: 2001:1601 (default for vrf vrf1601)
*> 20.13.1.1/32 192.13.26.5 0 7501 i
*> 20.13.1.2/32 192.13.26.5 0 7501 i
*> 20.13.1.3/32 192.13.26.5 0 7501 i
*> 20.13.1.4/32 192.13.26.5 0 7501 i
*> 20.13.1.5/32 192.13.26.5 0 7501 i
*>i20.14.1.1/3214.14.14.1 100 0 8501 i
*>i20.14.1.2/3214.14.14.1 100 0 8501 i
*>i20.14.1.3/3214.14.14.1 100 0 8501 i
*>i20.14.1.4/3214.14.14.1 100 0 8501 i
*>i20.14.1.5/3214.14.14.1 100 0 8501 i
Related Topics
• Configure the Core Network, on page 9
• Define VRFs on PE Routers to Enable Customer Connectivity, on page 16
For more details on Multiprotocol BGP, see BGP Configuration Guide for Cisco NCS 540 Series Routers.
Associated Commands
Connect MPLS VPN Customers
Connecting MPLS VPN customers involves these main tasks:
• Define VRFs on PE Routers to Enable Customer Connectivity, on page 16
• Configure VRF Interfaces on PE Routers for Each VPN Customer, on page 17
• Configure the Routing Protocol between the PE and CE Routers
Use any of these options:
L3VPN Configuration Guide for Cisco NCS 540 Series Routers, IOS XR Release 6.3.x
15
MPLS L3VPN Overview
Connect MPLS VPN Customers
