Router-PE1#show vrf vrf1601
VRF RD RT AFI SAFI
vrf1601 2001:1601
import 2001:1601 IPV4 Unicast
export 2001:1601 IPV4 Unicast
Related Topics
• Configure VRF Interfaces on PE Routers for Each VPN Customer, on page 17
• Configure Multiprotocol BGP on the PE Routers and Route Reflectors, on page 12
Configure VRF Interfaces on PE Routers for Each VPN Customer
After a VRF instance is created, you must associate that VRF instance with an interface or a sub-interface on
the PE routers.
You must remove the IPv4 or IPv6 addresses from an interface prior to assigning, removing, or changing an
interface's VRF. If this is not done in advance, any attempt to change the VRF on an IP interface is rejected.
Note
Configuration Example
This example assigns an IP address 192.13.26.6 to the interface (HundredGigE0/0/1/0.1601) on PE1 router
and associates the VRF instance vrf1601, to that interface.
Router-PE1#configure
Router-PE1(config)#interface HundredGigE0/0/1/0.1601
Router-PE1(config-if)#vrf vrf1601
Router-PE1(config-if)#ipv4 address 192.13.26.6 255.255.255.252
Router-PE1(config-if)#encapsulation dot1q 1601
Router-PE1(config)#commit
Running Configuration
interface HundredGigE0/0/1/0.1601
vrf vrf1601
ipv4 address 192.13.26.6 255.255.255.252
encapsulation dot1q 1601
!
Verification
• Verify that the interface with which the VRF is associated, is UP.
Router-PE1#show ipv4 vrf vrf1601 interface
HundredGigE0/0/1/0.1601 is Up, ipv4 protocol is Up
Vrf is vrf1601 (vrfid 0x60000001)
Internet address is 192.13.26.6/30
MTU is 1518 (1500 is available to IP)
Helper address is not set
L3VPN Configuration Guide for Cisco NCS 540 Series Routers, IOS XR Release 6.3.x
17
MPLS L3VPN Overview
Configure VRF Interfaces on PE Routers for Each VPN Customer
