D14908.02 SX20 Administrator Guide TC6.0, JANUARY 2013. www.cisco.com — Copyright © 2012-2013 Cisco Systems, Inc. All rights reserved.
3
Cisco TelePresence SX20 Quick Set Administrator Guide
Appendices ........................................................................ 104
Power button and LED indicator .......................................... 105
Connecting the Cisco TelePresence Touch 8” controller .... 106
Rear panel ............................................................................ 107
Pin-out schemes ................................................................. 108
About monitors .................................................................... 109
Optimal definition profiles .....................................................110
ClearPath — Packet loss resilience .......................................111
Requirement for speaker systems connected to a
Cisco TelePresence C Series codec ....................................112
Factory resetting ...................................................................113
Factory resetting the Touch 8” controller .............................114
Technical specification for SX20 Quick Set ..........................115
Supported RFCs ...................................................................117
User documentation on the Cisco web site ..........................118
Intellectual property rights ....................................................119
Cisco contacts ....................................................................119
Contents
