Cisco WAP571 User Manual

9 Cisco WAP571 Wireless Access Point
STEP 1 Verify that the Cisco WAP571 is powered on and the lights indicate
the appropriate links.
STEP 2 Locate the device’s IP address. While there are different ways to
locate your device’s IP address, this procedure uses Cisco FindIT.
a. If you have previously downloaded Cisco FindIT, open Internet
Explorer and launch Cisco FindIT. For more information on
downloading Cisco FindIT, see www.cisco.com/go/findit.
b. In the Cisco FindIT display, place your mouse over the device’s
name. The device IP address is displayed along with other
device information.
STEP 3 Open a command window by choosing Start > Run and enter
cmd.
STEP 4 At the command window prompt, enter ping and the device IP
address. In this example, we pinged 192.0.2.10.
If successful, you should get a reply similar to the following:
Pinging 192.0.2.10 with 32 bytes of data:
Reply from 192.0.2.10: bytes=32 time<1ms TTL=128
If it fails, you should get a reply similar to the following:
Pinging 192.0.2.10 with 32 bytes of data:
Request timed out.
Possible Cause of Installation Failure
No Power
• Power up the switch and your computer if they are turned off.
• Make sure your PoE switch is powered on and the lights indicate that
you have a link. See Verifying the Hardware Installation, page 6.
• Verify that the devices on your network are not plugged into a
switchable outlet.
Bad Ethernet Connection
• Check the state of the indicator lights. See Verifying the Hardware
Installation, page 6.
• Check the Ethernet cable to ensure that it is firmly connected to your
devices. Devices connected by the Ethernet cable can include the WAP
device, and routers, any switches, and your computer.
• Verify the connected switch has auto-negotiation enabled. The access
point and the switch need the same negotiation parameters set.

Cisco WAP571 Specifications

General

2.4 GHz	Yes
Bandwidth	5 GHz
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, OFDM, QPSK
Number of users	200 user(s)
Channels quantity	155 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Receiver sensitivity	2.4 GHz 802.11b: -86 dBm 11Mbps 802.11g: -74 dBm 54 Mbps 802.11n(HT20): -71 dBm MCS7 802.11n(HT40): -68 dBm MCS7 5 GHz 802.11a: -90 dBm 6 Mbps 802.11a: -75 dBm 54 Mbps 802.11ac(HT20): -63 dBm MCS9 802.11ac(HT40): -60 dBm MCS9 802.11ac(HT80): -58 dBm MCS9
Throughput data rate	1900 Mbit/s
Spread spectrum method	DSSS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	600 Mbit/s
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Security algorithms	HTTPS, SNMP, SSID, WDS, WPA, WPA2
Auto Wireless Distribution System (WDS)	No
Placement	Ceiling, Table, Wall
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15.247, 15.407, RSS-210, EN 300.328, EN 301.893, AS/NZS 4268.2003, FCC 15.107 + 15.109, ICES-003, EN 301.489-1 + -17
Product color	White
Cable lock slot type	Kensington
Supported network protocols	NTP, HTTP/HTTPS, IPv6
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Antennas quantity	6
Antenna gain level (max)	1.99 dBi
Power consumption (max)	18 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Width	230 mm
Height	40 mm
Weight	778 g
