Cisco WAP571 User Manual

Cisco WAP571 Wireless Access Point 12
Where to Go From Here
Support
Cisco Support
Community
www.cisco.com/go/smallbizsupport
Cisco Support and
Resources
www.cisco.com/go/smallbizhelp
Phone Support Contacts www.cisco.com/en/US/support/
tsd_cisco_small_business
_support_center_contacts.html
Cisco Firmware
Downloads
www.cisco.com/go/smallbizfirmware
Select a link to download firmware for Cisco
Products. No login is required.
Cisco Open Source
Requests
www.cisco.com/go/
smallbiz_opensource_request
Cisco Partner Central
(Partner Login Required)
www.cisco.com/web/partners/sell/smb
Product Documentation
Cisco WAP571
Administration Guide
www.cisco.com/go/300_wap_resources
Cisco Power Adapters www.cisco.com/go/wap_accessories

Cisco WAP571 Specifications

General

2.4 GHz	Yes
Bandwidth	5 GHz
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, OFDM, QPSK
Number of users	200 user(s)
Channels quantity	155 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Receiver sensitivity	2.4 GHz 802.11b: -86 dBm 11Mbps 802.11g: -74 dBm 54 Mbps 802.11n(HT20): -71 dBm MCS7 802.11n(HT40): -68 dBm MCS7 5 GHz 802.11a: -90 dBm 6 Mbps 802.11a: -75 dBm 54 Mbps 802.11ac(HT20): -63 dBm MCS9 802.11ac(HT40): -60 dBm MCS9 802.11ac(HT80): -58 dBm MCS9
Throughput data rate	1900 Mbit/s
Spread spectrum method	DSSS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	600 Mbit/s
Flash memory	128 MB
Internal memory	256 MB
Operating system installed	Linux
Security algorithms	HTTPS, SNMP, SSID, WDS, WPA, WPA2
Auto Wireless Distribution System (WDS)	No
Placement	Ceiling, Table, Wall
Certification	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15.247, 15.407, RSS-210, EN 300.328, EN 301.893, AS/NZS 4268.2003, FCC 15.107 + 15.109, ICES-003, EN 301.489-1 + -17
Product color	White
Cable lock slot type	Kensington
Supported network protocols	NTP, HTTP/HTTPS, IPv6
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	2
Antenna features	Integrated antenna
Antennas quantity	6
Antenna gain level (max)	1.99 dBi
Power consumption (max)	18 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Width	230 mm
Height	40 mm
Weight	778 g
