54
Comfor t
C1_en_Chap03_confort_ed01-2015
Manual air conditioning
The system only operates with the engine running.
F Turn the control knob from
blue (cold) to red (hot) to
adjust the temperature to your
requirements.
Temperature level
adjustment
Air flow adjustment
F Turn the control knob from
position 1 to position 4 to obtain
a comfortable air flow.
If you put the air flow control in
position 0 (system off), the temperature is no
longer controlled. However, a slight flow of air
can still be felt, resulting from the movement of
the vehicle.
Air distribution adjustment
Centre and side vents.
Centre and side air vents, footwells.
Footwells.
Windscreen and footwells.
Windscreen.
