ENGINE
VALVE CLEARANCE SETTINGS
The valve clearances must be checked with the engine cold
● Inlet
Petrol all types
(Except16V-NFU)
NFU
Petrol - 16V all types
1.4 HDi
1.4 HDi 16V
Diesel 2.0 HDi
Diesel all types
(Except Diesel 1.4 HDi
1.4 HDi 16V
2.0 HDi)
0,20 mm ± 0,05
Exhaust
0,40 mm ± 0,05
Hydraulic adjustment
1 mm ± 0,05
1 mm ± 0,05
Rocking
Adjust
1 ● 1
3 ● 3
4 ● 4
2 ● 2
4 ● 4
2 ● 2
1 ● 1
3 ● 3
Inlet
●
Adjust
Rocking
Valves fully
open
Adjust
1
3
4
2
3 ● 4
4
● 2
2
● 1
1
● 3
Fully open (Exhaust)
POSSIBLE PROCEDURES
For engines with 4 cylinders in a line (1-3-4-2 )
Engines without hydraulic
adjustment: the clearance (J)
should be checked opposite the
cam.
B1DP13QC
0,15 mm ± 0,08
0,30 mm ± 0,08
