190
187, 190
A. Left hand front seat belt not fastened or
unfastened warning lamp.
B. Right hand front seat belt not fastened or
unfastened warning lamp.
C. Right hand rear seat belt not fastened or
unfastened warning lamp.
D. Centre rear seat belt not fastened or
unfastened warning lamp.
Front seat belts and
passenger's front airbag
E. Left hand rear seat belt not fastened or
unfastened warning lamp.
F. Front passenger's airbag deactivated
warning lamp.
G. Front passenger's airbag activated warning
lamp.
1. Open the glove box.
2. Insert the key (integral with the electronic key).
3. Select position:
"ON" (activation), with front passenger or
"forwards facing" child seat,
"OFF" (deactivation), with "rear facing" child seat.
4. Remove the key keeping the switch in the new
position.
Front passenger's airbag
Passenger safety
