CONTENTS
1)
BEFORE
STARTING
18
2)
PACKAGE
CONTENTS
18
3)
GENERAL
CAUTIONS
18
4)
CAUTIONS
ON
INSTALLATION
19
5)
INSTALLING
THE
SOURCE
UNIT
19
6)
REMOVING
THE
SOURCE
UNIT
21
7)
WIRING
AND
CONNECTIONS
22
8)
CONNECTING
THE
ACCESSORIES
23
1)
Before Starting
1.
This set is exclusively for use
in
cars with a
negative ground 12 V power supply.
2.
Read these instructions carefully.
3.
Be sure to disconnect the battery "terminal"
before starting. This is to prevent short circuits
during installation. (Figure
1)
Car
battery
2)
Package Contents
Figure
1
Source unit 1
Front panel 1
Trim ring 1
Mounting bracket 1
Special screw 1
Screws M5x6 mm 4
3)
General Cautions
1.
Do not open the case. There are no
user- serviceable parts inside.
If
you
drop anything into the unit during
installation, consult your dealer or
an
authorized Clarion service center.
18
CZ100
L-key 2
Wire connector 1
Remote control unit (with battery) 1
Owner's manual 1
Warranty card , 1
2.
Use a soft, dry cloth to clean the case.
Never use a rough cloth, thinner,
benzine,
or
alcohol etc. For tough dirt,
apply a little cold or warm water to a
soft cloth and wipe off the dirt gently.
To Next Page
