4. OPERATIONS
12 VT1010E/VT1510E
4. OPERATIONS
The monitor and DVD player provide the video; headphones provide the audio. The unit
receives power from the power circuit of the car’s dome light, which is replaced by the unit.
OPENING THE MONITOR
1. Press the monitor release button to lower the overhead monitor screen.
Looking up at the monitor from directly below.
2. Gently swing the LCD down and adjust the angle for viewing.
The monitor turns on automatically when you fully open it (assuming the ignition switch
is on or in the ACC position).
CAUTION!
The LCD opens to a maximum angle of 150 degrees.
Do not attempt to open it further.
CLOSING THE MONITOR
Gently push the back side of the display panel until it clicks into the overhead housing. The
monitor turns off automatically when you return it to the closed position.
Monitor Release button
150
maximum angle
Monitor open
