8. SPECIFICATIONS
VT1010E/VT1510E 31
8. SPECIFICATIONS
VT1010E VT1510E
Power supply (car battery) 12V DC (10V-16V)
Test voltage 14V, negative ground
Operating current <20.7W
Current consumption <82.8mW
Max current consumption <27.6W
Mechanism Manual open and close
Video system Auto, NTSC and PAL
Screen 10.2”diagonal 15.4”diagonal
Resolution (pixels) 800 x 480 1280 x 800
Display angle Vertical adjustable up and down; maximum angle 150°
Viewing angle (up/down/left/right) 45/65/65/65 10/30/40/40
Weight 4.959 lbs (2.25kg) 7.6 lbs (3.45kg)
Video signal 1Vp-p, 75-Ohm load
Operating temperature 23 ~ 131°F (-5 ~ 55° C)
Storage temperature -4 ~ 158°F (-20 ~ 70° C)
Dome light 2W
Note:
For the sake of technical improvements, this technical data and the design of the
equipment may change without prior notice.
