COMPONENT PARTS LIST
When ordering spare parts from the above list, please quote HEBWENT01-47
P/N
O DESCRIPTION P/NO DESCRIPTION
1 Base Panel 25 Front Panel
2 Leg 26 Main Door Frame
3 Washer 8x30mm 27 Hinge Pin
4 Hex Leg Securing Bolt 8x25mm 28 Fire Rope Gasket (large)
5 Rear Air Inlet Linkage System 29 Fire Rope Gasket (glass)
6 Stainless Steel Knob 30 Glass Panel
7 Ash Pan 31 Tab Retaining Socket Hd Bolt
8 Ash Pan Handle 32 Glass Securing Tab
9 Right Firebrick 33 Air Inlet Disc
10 Left Firebrick 34 Mounting Stud
11 Rear Firebrick 35 Vent Retaining Nut
12 Grate Shaker 36 Door Latch Tab
13 Grate 37 Spring Washer
14 Grate Shaker Linkage 38 Handle Retaining Nut
15 Stainless Steel Knob 39 Door Handle Shank
16 Left Side Panel 40 Stainless Steel Handle
17 Right Side panel 41 Upper Air Control Plate 1
18 Panel Retaining Bolt 42 Upper Air Control Plate 2
19 Washer 43 Stainless Steel Knob
20 Nut 44 Upper Air inlet Cover Plate
21 Rear Panel 45 Top Panel
22 Flue Blanking Plate 46 Flue Adaptor
23 Fire Rope Gasket 47 Nut
24 Baffle Plate
To Next Page
