Clevo D900T Service Manual

Introduction
1 - 8 External Locator - Bottom View
1.Introduction
External Locator - Bottom View
Figure 1 - 4
Bottom View
1. Battery
2. Vent/Fan Intake
3. Memory (RAM)
Cover
4. Hard Disk Cover
5. Sub Woofer
6. CPU Cover
7. Video Card Cover
1
2
4
5
3
6
2
2
2
7
