Clevo NP50DB User Manual

Disassembly
2 - 6 Removing the Battery
2.Disassembly
Removing the Battery
1. Turn the computer off, and remove the keyboard (page 2 - 5).
2. Remove screws
- (Figure 2a).
3. Remove the SD card cover and screws - (Figure 2b).
4. Carefully lift the bottom case
up in the direction of the arrow at point - and remove it (Figure 2c).
1
2
6
3
4
16
17
18
19
Figure 2
Battery Removal
a. Remove the screws.
b. Remove the SD cover
and screws.
c. Remove the bottom case.
2
a.
c.
3
6
4
5
13
7
18
8
9
11
12
14
10
b.
17
15
1
19
17
16

3. SD Card Cover
17. Bottom Case
•15 Screws
