CLIVET MC2-Y 53M User Manual

Specifications
 Page 22 
625
-15
TC 5.62 5.62 5.62 5.68 5.90 5.90 5.90 5.90 6.06 6.06 6.06 6.06 6.43 6.43 6.43 6.43
S/T 0.68 0.75 0.98 1.00 0.55 0.63 0.70 0.76 0.49 0.56 0.63 0.70 0.36 0.42 0.48 0.55
PI 1.11 1.11 1.11 1.11 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10
-10
TC 5.59 5.59 5.59 5.65 5.87 5.87 5.87 5.87 6.03 6.03 6.03 6.03 6.40 6.40 6.40 6.40
S/T 0.68 0.76 0.99 1.00 0.55 0.63 0.70 0.77 0.49 0.56 0.63 0.71 0.36 0.43 0.49 0.55
PI 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.11 1.11 1.11 1.11
-5
TC 5.56 5.56 5.56 5.62 5.85 5.85 5.85 5.85 6.00 6.00 6.00 6.00 6.39 6.39 6.39 6.39
S/T 0.68 0.76 0.99 1.00 0.56 0.63 0.70 0.77 0.50 0.57 0.63 0.71 0.36 0.43 0.49 0.56
PI 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.11 1.11 1.11 1.11
0
TC 5.53 5.53 5.53 5.59 5.83 5.83 5.83 5.83 5.99 5.99 5.99 5.99 6.38 6.38 6.38 6.38
S/T 0.69 0.76 1.00 1.00 0.56 0.64 0.71 0.77 0.50 0.57 0.64 0.72 0.36 0.43 0.49 0.56
PI 1.11 1.11 1.11 1.11 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.10 1.11 1.11 1.11 1.11
5
TC 5.50 5.50 5.50 5.56 5.80 5.80 5.80 5.80 5.97 5.97 5.97 5.97 6.38 6.38 6.38 6.38
S/T 0.69 0.77 1.00 1.00 0.56 0.64 0.71 0.78 0.50 0.57 0.64 0.72 0.36 0.43 0.49 0.56
PI 1.12 1.12 1.12 1.12 1.11 1.11 1.11 1.11 1.11 1.11 1.11 1.11 1.12 1.12 1.12 1.12
10
TC 5.47 5.47 5.47 5.53 5.78 5.78 5.78 5.78 5.94 5.94 5.94 5.94 6.36 6.36 6.36 6.36
S/T 0.69 0.77 1.00 1.00 0.56 0.64 0.71 0.78 0.50 0.57 0.64 0.72 0.37 0.44 0.50 0.56
PI 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13
15
TC 5.42 5.42 5.42 5.48 5.74 5.74 5.74 5.74 5.91 5.91 5.91 5.91 6.33 6.33 6.33 6.33
S/T 0.70 0.78 0.86 0.93 0.57 0.65 0.72 0.79 0.51 0.58 0.65 0.73 0.37 0.44 0.50 0.57
PI 1.16 1.16 1.16 1.16 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.15 1.16 1.16 1.16 1.16
20
TC 5.36 5.36 5.36 5.42 5.68 5.68 5.68 5.68 5.85 5.85 5.85 5.85 6.28 6.28 6.28 6.28
S/T 0.70 0.78 0.86 0.93 0.57 0.65 0.72 0.79 0.51 0.58 0.65 0.73 0.37 0.44 0.50 0.57
PI 1.20 1.20 1.20 1.20 1.19 1.19 1.19 1.19 1.19 1.19 1.19 1.19 1.19 1.19 1.19 1.19
25
TC 5.10 5.10 5.10 5.16 5.42 5.42 5.42 5.42 5.59 5.59 5.59 5.59 6.02 6.02 6.02 6.02
S/T 0.71 0.79 0.87 0.95 0.58 0.65 0.73 0.81 0.51 0.59 0.66 0.74 0.37 0.44 0.51 0.58
PI 1.32 1.32 1.32 1.32 1.32 1.32 1.32 1.32 1.32 1.32 1.32 1.32 1.32 1.32 1.32 1.32
30
TC 4.87 4.87 4.93 4.99 5.19 5.19 5.19 5.19 5.33 5.33 5.33 5.33 5.76 5.76 5.76 5.76
S/T 0.72 0.80 0.89 0.97 0.58 0.66 0.74 0.82 0.51 0.59 0.67 0.75 0.36 0.44 0.51 0.58
PI 1.45 1.45 1.45 1.45 1.46 1.46 1.46 1.46 1.46 1.46 1.46 1.46 1.46 1.46 1.46 1.46
35
TC 4.62 4.62 4.67 4.73 4.93 4.93 4.93 4.93 5.07 5.07 5.16 5.07 5.48 5.48 5.48 5.48
S/T 0.73 0.82 0.91 0.99 0.58 0.67 0.75 0.84 0.52 0.60 0.68 0.76 0.36 0.44 0.51 0.59
PI 1.58 1.58 1.58 1.58 1.59 1.59 1.59 1.59 1.59 1.59 1.60 1.59 1.59 1.59 1.59 1.59
40
TC 4.34 4.34 4.38 4.43 4.63 4.63 4.63 4.65 4.77 4.77 4.82 4.77 5.16 5.16 5.16 5.16
S/T 0.75 0.85 0.94 1.00 0.59 0.68 0.78 0.87 0.52 0.61 0.70 0.79 0.35 0.44 0.52 0.60
PI 1.74 1.74 1.74 1.74 1.75 1.75 1.75 1.75 1.75 1.75 1.76 1.75 1.76 1.76 1.76 1.76
46
TC 4.03 4.03 4.06 4.09 4.29 4.29 4.29 4.34 4.43 4.43 4.43 4.43 4.80 4.80 4.80 4.80
S/T 0.76 0.86 0.96 1.00 0.60 0.69 0.79 0.88 0.52 0.62 0.71 0.80 0.35 0.44 0.52 0.61
PI 1.94 1.94 1.94 1.94 1.95 1.95 1.95 1.95 1.95 1.95 1.95 1.95 1.97 1.97 1.97 1.97
50
TC 3.77 3.80 3.83 3.86 4.03 4.03 4.03 4.06 4.17 4.17 4.17 4.17 4.51 4.51 4.51 4.51
S/T 0.78 0.88 0.99 1.00 0.60 0.71 0.81 0.91 0.53 0.63 0.73 0.83 0.35 0.44 0.53 0.91
PI 2.11 2.11 2.11 2.11 2.11 2.11 2.11 2.11 2.12 2.12 2.12 2.12 2.14 2.14 2.14 2.14
720
-15
TC 5.74 5.74 5.80 5.86 6.05 6.05 6.05 6.05 6.20 6.20 6.20 6.20 6.57 6.57 6.57 6.57
S/T 0.70 0.78 1.00 1.00 0.56 0.64 0.72 0.98 0.49 0.57 0.66 0.73 0.35 0.42 0.49 0.57
PI 1.14 1.14 1.14 1.14 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.12 1.12 1.12 1.12
-10
TC 5.71 5.71 5.77 5.83 6.02 6.02 6.02 6.02 6.17 6.17 6.17 6.17 6.55 6.55 6.55 6.55
S/T 0.70 0.79 1.00 1.00 0.56 0.64 0.73 0.98 0.49 0.57 0.66 0.74 0.35 0.43 0.49 0.57
PI 1.13 1.13 1.13 1.13 1.12 1.12 1.12 1.12 1.13 1.13 1.13 1.13 1.12 1.12 1.12 1.12
-5
TC 5.67 5.67 5.73 5.79 6.00 6.00 6.00 6.00 6.15 6.15 6.15 6.15 6.53 6.53 6.53 6.53
S/T 0.70 0.79 1.00 1.00 0.57 0.64 0.73 0.99 0.50 0.58 0.66 0.74 0.35 0.43 0.50 0.58
PI 1.13 1.13 1.13 1.13 1.12 1.12 1.12 1.12 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13
0
TC 5.65 5.65 5.71 5.76 5.97 5.97 5.97 5.97 6.13 6.13 6.13 6.13 6.53 6.53 6.53 6.53
S/T 0.71 0.79 1.00 1.00 0.57 0.65 0.74 0.99 0.50 0.58 0.67 0.74 0.35 0.43 0.50 0.58
PI 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13 1.13
5
TC 5.62 5.62 5.68 5.74 5.95 5.95 5.95 5.95 6.11 6.11 6.11 6.11 6.52 6.52 6.52 6.52
S/T 0.71 0.80 1.00 1.00 0.57 0.65 0.74 1.00 0.50 0.58 0.67 0.75 0.35 0.43 0.50 0.58
PI 1.14 1.14 1.14 1.14 1.14 1.14 1.14 1.14 1.14 1.14 1.14 1.14 1.14 1.14 1.14 1.14
10
TC 5.58 5.58 5.64 5.70 5.92 5.92 5.92 5.92 6.09 6.09 6.09 6.09 6.51 6.51 6.51 6.51
S/T 0.71 0.80 1.00 1.00 0.57 0.65 0.74 1.00 0.50 0.58 0.67 0.75 0.36 0.44 0.50 0.58
PI 1.16 1.16 1.16 1.16 1.15 1.15 1.15 1.15 1.16 1.16 1.16 1.16 1.15 1.15 1.15 1.15
15
TC 5.54 5.54 5.60 5.65 5.88 5.88 5.88 5.88 6.05 6.05 6.05 6.05 6.48 6.48 6.48 6.48
S/T 0.72 0.81 0.90 0.98 0.58 0.66 0.75 0.83 0.51 0.59 0.68 0.76 0.36 0.44 0.51 0.59
PI 1.19 1.19 1.19 1.19 1.18 1.18 1.18 1.18 1.18 1.18 1.18 1.18 1.18 1.18 1.18 1.18
20
TC 5.48 5.48 5.53 5.59 5.82 5.82 5.82 5.82 5.99 5.99 5.99 5.99 6.42 6.42 6.42 6.42
S/T 0.72 0.81 0.90 0.98 0.58 0.66 0.75 0.83 0.51 0.59 0.68 0.76 0.36 0.44 0.51 0.59
PI 1.23 1.23 1.23 1.23 1.22 1.22 1.22 1.22 1.22 1.22 1.22 1.22 1.21 1.21 1.21 1.21
25
TC 5.22 5.22 5.28 5.33 5.56 5.56 5.56 5.56 5.73 5.73 5.73 5.73 6.16 6.16 6.16 6.16
S/T 0.73 0.83 0.91 1.00 0.58 0.67 0.76 0.84 0.52 0.60 0.68 0.77 0.36 0.44 0.51 0.59
PI 1.35 1.35 1.35 1.35 1.35 1.35 1.35 1.35 1.35 1.35 1.35 1.35 1.35 1.35 1.35 1.35
30
TC 4.99 4.99 5.05 5.10 5.30 5.30 5.30 5.30 5.45 5.45 5.45 5.45 5.88 5.88 5.88 5.88
S/T 0.74 0.84 0.93 1.00 0.59 0.68 0.77 0.86 0.52 0.61 0.70 0.78 0.35 0.44 0.52 0.60
PI 1.49 1.49 1.49 1.49 1.49 1.49 1.49 1.49 1.49 1.49 1.49 1.49 1.50 1.50 1.50 1.50
35
TC 4.73 4.73 4.79 4.85 5.05 5.05 5.05 5.05 5.19 5.19 5.28 5.19 5.59 5.59 5.59 5.59
S/T 0.75 0.86 0.95 1.00 0.59 0.69 0.79 0.88 0.52 0.61 0.70 0.80 0.35 0.44 0.52 0.61
PI 1.62 1.62 1.62 1.62 1.62 1.62 1.62 1.62 1.63 1.63 1.63 1.63 1.64 1.64 1.64 1.64
40
TC 4.44 4.45 4.50 4.54 4.74 4.74 4.74 4.77 4.89 4.89 4.93 4.89 5.27 5.27 5.27 5.27
S/T 0.78 0.89 0.99 1.00 0.61 0.71 0.82 0.92 0.53 0.63 0.73 0.83 0.35 0.44 0.53 0.90
PI 1.79 1.79 1.79 1.79 1.79 1.79 1.79 1.79 1.80 1.80 1.80 1.80 1.81 1.81 1.81 1.81
46
TC 4.11 4.14 4.17 4.20 4.40 4.40 4.40 4.46 4.54 4.54 4.54 4.54 4.91 4.91 4.91 4.91
S/T 0.79 0.90 1.00 1.00 0.61 0.72 0.83 0.93 0.53 0.64 0.74 0.85 0.34 0.44 0.54 0.92
PI 1.99 1.99 1.99 1.99 1.99 1.99 1.99 1.99 2.00 2.00 2.00 2.00 2.02 2.02 2.02 2.02
50
TC 3.86 3.89 3.91 3.94 4.11 4.11 4.11 4.14 4.26 4.26 4.26 4.26 4.63 4.63 4.63 4.63
S/T 0.81 0.93 1.00 1.00 0.62 0.74 0.86 0.97 0.54 0.65 0.76 0.87 0.34 0.44 0.55 0.97
PI 2.15 2.15 2.15 2.15 2.16 2.16 2.16 2.16 2.17 2.17 2.17 2.17 2.19 2.19 2.19 2.19
TC:Total Cooling Capacity (kW)
S/T:Sensible Cooling Capacity Ratio
PI:Power Input(kW)
Note: The table shows the case where the operation frequency of a compressor is fixed.
