20
MANUEL D’INSTALLATION GLOBE 3800
TABLEAU DES FONCTIONS DE BASE
TABLEAU DES FONCTIONS AVANCEES
1
ANTIDISTRACTION DISPOSITIF D'IMMOBILISATION
2
ANTIDISTRACTION ALARME
3 POLARITE POSITIVE ENTREE
PERIMETRIQUE
4 NON UTILISEE
5 NON UTILISEE
6
ANTIVOL AUTOMATIQUE
7
ANTIVOL VOLONTAIRE
8 BLOCAGE MOTEUR ANTIVOL CONTROLE PAR LE DETECTEUR DE DEPLACEMENT
1 AUTO-APPRENTISSAGE page 17
3 NON UTILISEE
4 SIGNALISATION DE PORTES / CAPOT / COFFRE OUVERTS
5 CLIGNOTANT D'ACTIVATION / DESACTIVATION
6 ACTIVATION AUTOMATIQUE DE L'ALARME
7
ACTIVATION AUTOMATIQUE ANTIDEMARRAGE
8
ALARME ANTIDEMARRAGE
2 NON UTILISEE
désactivée
désactivée
désactivée
activée
activée
activée
désactivée
désactivée
activée
activée
activée
activée
activée
désactivée
désactivée
désactivée
désactivée
désactivée
activée
activée
désactivée
activée
Vol -Vol +
activée
désactivée
PROGRAMMATION DE FABRIQUE
Clignotement long
Clignotement court
TABLEAU DU BUZZER
VOLUME BUZZER
MAX.
1 s
MIN.
2 s
29
GLOBE 3800 INSTALLATION MANUAL
HOW TO CONFIGURE THE POSITIVE PERIMETRIC INPUT (PINK/BLACK wire).
activate line 3 of the advanced functions table as indicated overleaf. After programming, the
PINK/BLACK wire will no longer act as sensor input but as perimetric input, while the BLUE/
PINK wire will act as sensor input.
+ 30
+ 30
Þ
BLUE / PINK PINK / BLACK
ATTENTION!
This product is preset to comply with EC Directives for alarm systems. The buzzer function may
only be activated in non European Countries or the homologation will be invalidated.
Disconnect the negative terminal from the battery before starting the installation of
the system.
This system is compatible with 12 volt negative ground vehicles.
INTRODUCTION
This alarm has a self-learning system of a recurring sequence of signals of the vehicle when
doors are closed/opened by original radio control.
The signals normally in use are: doors actuator, doors lock key cylinder switches, turn indicators.
In case of connection to the turn indicators for activation/deactivation of the alarm please note that:
• it is necessary to let the complete sequence finished before opening the door.
• the system could not arm/disarm when the vehicle emergency blinker is activated.
POSITIONING THE COMPONENTS OF THE SYSTEM
All the parts of the system should be installed in hidden locations which are difficult to access
and away from heat sources.
Alarm unit
Fit in the engine compartment taking care of
orienting it as indicated in the drawing.
K.O.
O.K.
06DE2086A.pmd 17/01/2005, 14.3020
