Analog input: Cold temp 4
If there is an additional terminal board between a thermocouple and the IS-AIN8
module and there is a significant temperature difference between this terminal
board and the module, it is necessary to measure the temperature at this terminal
board and use this temperature for the thermocouple compensation instead of the
internal temperature of the module.
This analog input is intended for measuement of this thermocouple compensation
temperature for the IS-AIN8 module with index #4.
NOTE:
Thermocouples without internal compensation "Thermo(nc)..." must be used for
this case.
Table of binary output functions
Binary output: Alarm
The output is closed if there is at least one unconfirmed alarm in the alarm list.
NOTE:
Some alarm types as e.g. Off load, History record, Low power, Mains protection do
not require confirmation, they disappear from the alarm list automatically when the
alarm condition disappears. That means the Alarm output is not activated by
alarms of these types.
