IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
Setpoint groups
1. ProcessControl
2. Basic settings
3. Comms settings
4. ComProtSettings
5. Analog protect
6. Bank protect
7. Pwr Management
8. Sync/Load ctrl
9. Volt/PF ctrl
10. Force value
11. Load shedding
12. Timer settings
13. Act. calls/SMS
14. Date/Time
CAUTION!
Do not perform repeated writing of setpoints (e.g. power control from a PLC by repeated writing of baseload
setpoint via Modbus) The setpoints are stored in EEPROM memory, which can be overwritten more than 10
5
times without risk of damage or data loss, but it may become damaged, when allowed number of writing
cycles is exceeded!
HINT
The descriptions of all available setpoints, values logical binary inputs and logical binary outputs that you can
find in next chapters are common for standard gen-set in MINT application and the Bank Controller. For the
purpose of this document, please consider the term “gen-set” as “Bank Controller”.
Table of setpoints
Group: ProcessControl
Setpoint: #SysBaseLoad
This setpoint is used to adjust the requested load for the whole gen-set group
in system baseload mode (i.e. #SysLdCtrl PtM = BASELOAD). Each gen-set
takes proprtionally equal part of this total required value. The number of running
gen-sets is resolved by the power management function according to the
requested total load, gen-sets nominal power and adjusted reserves.
OFF, 1 .. Nomin power [kW]
