Craftsman 139.53664SRT2 User Manual

Repair Parts
10
NOTICE
8
9
UP
CEILING MOUNT ONLY
11
17
18
14
15
16
13
1
LOCK
LIGHT
12
4
5
7
6
2
3B
FOR REMOTE MODEL
139.53681B
3A
2
FOR REMOTE MODEL
139.53681
TO GARAGE DOOR
1
2
4
4
7
RAIL GREASE
NO. 83A4
3
9
5
6
8
Rail Assembly Parts
Installation Parts
36
KEY PART
NO. NO. DESCRIPTION
1 1A995 Master link kit
2 41B3869 Complete trolley assembly
3 1B3117 T-rail – center section
4 183B110 T-rail – end section
5 41A3588-1 Belt pulley bracket
6 41A3589-12 Full belt assembly
7 83A4 Rail grease
8 41B4103 Tension assembly (Spring/Trolley Nut)
9 109B33 Trolley Clip
NOT SHOWN
41A3534 Rail assembly hardware kit (see page 7).
KEY PART
NO. NO. DESCRIPTION
1 41A4884 Premium control console
2 41A5032 3-function remote control housing
(no circuit board)
3A 10A19 3V 2016 Lithium battery (2 required)
3B 10A20 3V 2032 Lithium battery (1 required)
4 29B134 Visor clip
5 31D431 Keyless entry keypad cover
6 31B430 Keyless entry battery cover
710A29Volt battery
8 41A2828 Emergency rope & handle assembly
9 41A4353 Header bracket w/clevis pin & fastener
10 217A238 2-conductor bell wire – white & white/red
11 178B35 Curved door arm section
12 41A5047 Door bracket w/clevis pin & fastener
13 41A4373A Safety sensor kit (receiving and sending
eyes) with 3' 2-conductor bell wire attached
14 12B483 "C" Wrap Bracket
15 12B484 Square Hole Bracket
16 12B485 Slotted Bracket
17 12B350 Hanging brackets
18 178B34 Straight door arm section
NOT SHOWN
41A4437-5 Installation hardware bag (see page 7).
41A4116 Safety sensor hardware (see page 7).
114A2124 Owner's manual

Craftsman 139.53664SRT2 Specifications

General

Brand	Craftsman
Model	139.53664SRT2
Category	Garage Door Opener
Language	English
