Cub Cadet i1046 Parts Manual

i1046 & i1050/Series i1000 SECTION HM12
38
DANGER
KEEP HANDS AND FEET AWAY.
DO NOT OPERATE MOWER UNLESS CHUTE DEFLECTOR
OR ENTIRE GRASS CATCHER IS
IN ITS PROPER PLACE.
ASSEMBLE CHUTE DEFLECTOR TO THIS UNIT BEFORE OPERATING.
S30503
777S30503
777I22615
777X42472
UNDER HOOD
Blades 942-04053A (3) Ignition Keys 725-2054 Lower Drive Belt 954-04134 Deck Spindles 618-04126 (3)
Engine To Deck/Deck Spindle Belt
954-04077
Solenoid 725-04439
X42 474
Air Filter
KH-32-083-03-S
Pre-Cleaner/Element
KH-24-083-05-S
Spark Plug
KH-12-132-02 / 759-3336
F
uel Filter KH-25-050-22-S
Oil Filter KH-52-050-02 Oil Capacity 57.5 oz
M O D E L
i 1 0 4 6
R E P L A C E M E N T P A R T S
Us e on ly C ub C ad et g en ui ne f ac to ry p ar ts
w w w . c u b c a d e t . c o m
777D10615
Front Of Deck
46
C U T
777S32771
ROTATING BLADES CAUSE
SERIOUS INJURY OR DEATH
• DO NOT MOW WHENCHILDREN OR OTHERS ARE
AROUND
•
NEVERCARRYCHILDRENEVEN WITH BLADE(S)OFF.
• LOOK DOWN AND BEHIND BEFORE AND WHILE
BACKING.
• MOWING IN REVERSE ISNOT RECOMMENDED.
DANGER
TO AV OI D S ER IO US I NJ URY O R D EAT H
• GO UP AND DOWN SLOPES, NOT ACROSS. • AVOID SUDDEN TURNS. • DO NOT OPERATE THEUNIT WHERE ITCOULD SLIP OR TIP. • IF MACHINE ST OPS GOING UPHILL, STOP BLADE(S)
AND BACK DOWNHILL SLOWLY.
• KEEP SAFETY DEVICES ( GUARDS, SHIELDS, AND SWITCHES,
ETC.) IN PLACE ANDWORKING.
• REMOVE OBJECTSTHAT COULDBE THROWNBY THE BLADE(S). • KNOW L OCATIONAND FUNCTION OF AL L CONTROLS. • BE SURE BL ADE(S) AND ENGINE ARE STOPPED BEFORE
PLACING HANDS OR FEET NEAR BLADE(S) .
• BEFORE LEAVING OPERATOR'S POSITION,DISENGAGE BLADE(S),
ENGAGE PARKING BRAKE, SHUTOFF AND REMOVE KEY.
RE AD OP ERAT OR 'S MAN UAL
Gra ss C ollec tion Bag ging Syst em 42" Sno w Thr ower 42" Law n Swe eper 10 & 17 Cu. Ft. Dump Car ts
PULL HANDLE UP TO MOVE SEAT FORWARD
Tir e Ch ains Whe el W eight 46” Doz er Bl ade Trac tor Trun k Too l Box
HOW TO OPE RATE
TO START
OPERATING MODES
REVERSE CAUTION MODE
1. TURN KEY TO REVERSE CAUTION MODE POSITION. 2. DEPRESS REVERSE PUSH BUTTON. (RED INDICATOR LIGHT “ON”) WHEN RED LIGHTIS “ON” MACHINE CAN BE OPERATED IN REVERSE WITH
MOWER BLADES ENGAGED.
IMPORTANT: MOWING IN REVERSE IS NOT RECOMMENDED.
3. AFTER RESUMING FORWARD OPERATION, RETURN KEY TO “NORMAL MOWING” POSITION.
NOTE:
IN BOTH MODES, WHEN OPERATOR LEAVES SEAT, ENGINE WILL
STOP UNLESS PARKING BRAKE IS SET AND BLADES ARE DISENGAGED.
NORMAL MOWING YOU MUST DISENGAGE BLADES/PTO,
(POWERTAKE OFF)
BEFORE
T
RAVELING IN REVERSE.
1. DISENGAGE BLADES/PTO, (POWERTAKE OFF) 2. ENGAGE THE TRACTOR’S PARKING BRAKE. 3. SET THROTTLE TOFAST “RABBIT”POSITION ANDPULL CHOKE KNOB OUT. 4. TURN KEY TO START ENGINE. AFTER START RELEASE KEY& DEACTIVATECHOKE.
BRAKE/ CLUTCH
PEDAL
(LOCATED ON DRIVERS LEFT) (LOCATED ON DRIVERS RI GHT)
O P T I O N A L A T TA C H M E N T S
SEAT ADJUSTMENT
777X42426
Right Lens
For Headlight
777X42427
Left Lens
777I22702
On Dash Cluster
777D10608
Centered Over 777S32771
777I22679
Top Of Engine
777D10491
On Rear Fender
(QTY2) 777D10492
On Both Sides Place
As Shown
1046
777I22707
Place Right Of
Gas Guage
(QTY 2) 777I22708
Aside Trans.
Release Rods
Release Both Transmission Release
Levers B ef o r e M ov i ng V eh i cl e
Pull Rod Through Large Opening, Turn Lever To The Right And Release.
1 2
I22708 AC
WARNING
SHIELD MISSING
DO NOT OPERATE.
(QTY2) 777S32807
Place On Both
Gear Tops
777D10496
In Molded On Hood
777D10494
In Molded On Hood
777D10501
S
M A R T
J
E T
D
E C K
W
A S H
777D01782
On Rear
Hitch Plate
Gear Top
D10494
D10496
(QTY2) 777D10624
Near Each Nozzle
777S32815
On Hitch Plate
WHEN TOWING, GO SLOW
AND MAKE WIDE TURNS
TO AVOID JACK-KNIFING
N O T I C E
WARNING
777S30018
Model i1046 Labels
