Gear Top
777S32771
ROTATING BLADES CAUSE
SERIOUS INJURY OR DEATH
• DO NOT MOW WHENCHILDREN OR OTHERS ARE
AROUND
•
NEVERCARRYCHILDRENEVEN WITH BLADE(S)OFF.
• LOOK DOWN AND BEHIND BEFORE AND WHILE
BACKING.
• MOWING IN REVERSE ISNOT RECOMMENDED.
DANGER
TO AV OI D S ER IO US I NJ URY O R D EAT H
• GO UP AND DOWN SLOPES, NOT ACROSS.
• AVOID SUDDEN TURNS.
• DO NOT OPERATETHE UNIT WHERE ITCOULD SLIP OR TIP.
• IF MACHINE ST OPS GOING UPHILL, STOP BLADE(S)
AND BACK DOWNHILL SLOWLY.
• KEEP SAFETY DEVICES ( GUARDS, SHIELDS, AND SWITCHES,
ETC.) IN PLACEAND WORKING.
• REMOVE OBJECTSTHAT COULDBE THROWNBY THE BLADE(S).
• KNOW L OCATIONAND FUNCTION OF AL L CONTROLS.
• BE SURE BL ADE(S) AND ENGINE ARE STOPPED BEFORE
PLACING HANDS OR FEET NEAR BLADE(S) .
• BEFORE LEAVING OPERATOR'S POSITION,DISENGAGE BLADE(S),
ENGAGE PARKING BRAKE, SHUTOFF AND REMOVE KEY.
RE AD OP ERAT OR 'S MAN UAL
Gra ss C ollec tion Bag ging Syst em
42" Sno w Thr ower
42" Law n Swe eper
10 & 17 Cu. Ft. Dump Car ts
PULL HANDLE UP TO MOVE SEAT FORWARD
Tir e Ch ains
Whe el W eight
46” Doz er Bl ade
Trac tor Trun k Too l Box
HO W TO OP ERATE
TO START
OPERATING MODES
REVERSE CAUTION MODE
1. TURN KEY TO REVERSE CAUTION MODE POSITION.
2. DEPRESS REVERSE PUSH BUTTON. (RED INDICATOR LIGHT “ON”)
WHEN RED LIGHTIS “ON” MACHINE CAN BE OPERATED IN REVERSE
WITH
MOWER BLADES ENGAGED.
IMPORTANT: MOWING IN REVERSE IS NOT RECOMMENDED.
3. AFTER RESUMING FORWARD OPERATION, RETURN KEY TO
“NORMAL MOWING” POSITION.
NOTE:
IN BOTH MODES, WHEN OPERATOR LEAVES SEAT, ENGINE WILL
STOP UNLESS PARKING BRAKE IS SET AND BLADES ARE DISENGAGED.
NORMAL MOWING
YOU MUST DISENGAGE BLADES/PTO,
(POWERTAKE OFF)
BEFORE
T
RAVELING IN REVERSE.
1. DISENGAGE BLADES/PTO, (POWERTAKE OFF)
2. ENGAGE THE TRACTOR’S PARKING BRAKE.
3. SET THROTTLE TOFAST “RABBIT”POSITION ANDPULL CHOKE KNOB OUT.
4. TURN KEY TO START ENGINE. AFTER START RELEASE KEY& DEACTIVATECHOKE.
BRAKE/ CLUTCH
PEDAL
(LOCATED ON DRIVERS LEFT) (LOCATED ON DRIVERS RI GHT)
O P T I O N A L A T TA C H M E N T S
SEAT ADJUSTMENT
777X42426
Right Lens
For Headlight
777X42427
Left Lens
777D10608
Centered Over 777S32771
Blades 942-04124 (1) / 942-04125 (2)
Ignition Keys 725-2054
Lower Drive Belt 954-04134
Deck Spindles 918-0660 (3)
Engine To Deck/Deck Spindle Belt
954-04118
Solenoid 725-04439
X42 474
Air Filter
KH-12-083-10
Pre-Cleaner/Element
KH-12-083-12
Spark Plug
KH-12-132-02 / 759-3336
F
uel Filter KH-25-050-07-S
Oil Filter KH-12-050-08
Oil Capacity 57.5 oz
M O D E L
i 1 0 5 0
R E P L A C E M E N T P A R T S
Us e on ly C ub C ad et g en ui ne f ac to ry p ar ts
w w w . c u b c a d e t . c o m
• KEEP HANDS AND FEET AWAY FROM ROTATINGPARTS.
• R EMOVE OBJEC TS TH AT CAN BE THRO WN BY THE
BLADE IN ANY DIRE CTION. W EAR SAFET Y GLASSE S.
• DO NOT MOW WHEN CHILDREN OR OTHERS ARE AROUND.
NEVER CARRY CHILDREN EVEN WITH BLADES OFF.
• USE EXTRA CAUTIONON SLOPES. DO NOT MOW SLOPES
GREATER THAN 15°. MOW UP AND DOWN, NOT ACROSS.
AVOID SUDDEN TURNS, USE LOW SPEED.
READ OPERATOR'S MANUAL. KEEP SAFETY DEVICES IN PLACE AND WORKING.
S30015
