Cub Cadet i1046 Parts Manual

i1046 & i1050/Series i1000 SECTION HM12
7
Ref.
No.
Part No. Description
1 17239D Bracket, Seat Switch
2 647-04095 Shaft, Lift
3 683-04313 Seat Slide
4 710-04482 Screw, Hex Flange, 3/8-16 x .875 Gr5
5 710-1260A Screw, Hex Wash Hd. Tapp, 5/16-18 x .75
6 710-0451 Screw, Carriage, 5/16-18 x 75
7 710-0599 Screw, Hex Wash Hd. Tapp, 1/4-20 x .5
8 710-0726 Screw, Hex Wash Hd. Tapp, 5/16-12 x .75
9 710-0895 Screw, Hex Wash Hd. Tapp, 1/4-15 x .75
10 711-0332 Pin, Clevis, .5 x .78
11 711-04626 Pin, Seat Index
12 712-04063 Nut, Hex Flange Insert Lock, 5/16-18 GrF
13 712-04065 Nut, Hex Flange Insert Lock, 3/8-16 GrF
14 710-04187 Screw, Hex Wash Hd. H/L, 1/4-15 x .5
15 714-0104 Pin, Internal Cotter
16 714-0111 Pin, Cotter, 3/32 x 1.0
17 714-04023 Pin, Internal Cotter
18 716-0106A E-ring, .625 Shaft
19 720-0311 Grip, Handle
20 726-3046 Clip, Ratchet
21 731-04074 Spacer, Seat Adjustment
22 731-05477 Cover, Rear Fender RH
23 731-05518 Cover, Rear Fender LH
24 732-04074 Spring, Compression
25 732-04386 Spring, Seat Adjust
26 732-04442 Spring, Lift Torsion
27 732-0826A Spring, Extension, .865 x 4.68
28 732-1184 Spring, Extension, .84 x 4.6
Ref.
No.
Part No. Description
29 735-04078 Pad, Foot RH
30 735-04079 Pad, Foot LH
31 726-0221 Nut, Speed, .5
32 736-0272 Washer, Flat, .51 x 1.0 x .06
34 736-0192 Washer, Flat, .535 x .93 x .09
35 736-3078 Washer, Flat, .344 x 1.0 x .063 HT
36 738-0138A Bolt, Shoulder, .496 x 2.5:3/8-16
37 738-0380 Bolt, Shoulder, .5 x .27:3/8-16
38 738-0966A Bolt, Shoulder, .5 x .925:3/8-16
39 738-1011A Bolt, Shoulder, .5 x 2.23:3/8-16
40 738-0296 Bolt, Shoulder, .447 x .268:5/16-18
41 741-0225 Bearing, Hex Flange,
42 746-04369 Cable, Lift, 16.16 Lg
43 746-0968 Cable, Lift, 16.16 Lg
44 747-04613 Handle, Lift
45 756-1154 Pulley, Roller
46 757-04053 Seat, High Back
47 783-0678B Link, Deck Lift
48 783-0720C Bracket, Front Deck Adjust
49 783-04901 Fender, Rear
50 783-04977A Plate, Deck Lift
51 783-05307 Pedesta, Seat
52 783-05272 Plate, Seat Pivot
53 710-0227 Screw, Hex Wash Hd. Tapp, #8-18 x .5
54 726-0279 Plate, Insulator
55 725-1303 Switch, Outer Seat Spring
56 725-1439 Switch, Inner Seat Spring
57 726-0278 Plate, Insulator Boss
Seat, Fender & Deck Lift
