AES diagnostics and status information
Also under the AES/EBU Sub Menu is the AES Status Information option, which can be used to check
the incoming sample rate(s) and confirm that the data is being received correctly.
Pressing ENTER will first show
This display shows the correct operation of the two AES transmitters V1 and V2. The letter after each is
the silicon version (and is of no importance to the user).
Pressing ENTER again will show
This display shows the status of the AES receiver, input A. The sample rate the unit has been able to
lock to is shown, or UNLOCKED will be displayed in its place. The unit will lock to sample rates from 32kHz
up to and including 192kHz.
The unit's own processing sample rate is 96kHz, and AES output data is always at 96kHz. Internal
sample rate converters will translate all incoming rates to 96kHz – one converter for each AES input.
24
AES Device Status
V1: E V2: A
AES Device Status
V: 96k0
DSP-2060A
User’s Manual
