D-Link COVR-1100 User Manual

6D-Link COVR-1102 User Manual
Section 1 - Product Overview
COVR-1100 Rear Panel
1 Power Button Press the power button to power the device on or o.
2 Internet WAN Port Using an Ethernet cable, connect your broadband modem to this port.
3 Ethernet LAN Port Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles.
4 Power Connector Connect the included power adapter here to power on the device.
5 Reset Button Insert a paperclip in the hole, wait for 5 seconds, then release to reset the router to default settings.
1 2 3 4 5

D-Link COVR-1100 Specifications

General

Antenna type	Internal
Product type	Mesh router
Reset button	Yes
Certification	FCC, IC, CE, ErP, RoHS, Wi-Fi CERTIFIED EasyMesh
Product color	White
Maximum coverage	185 m²
Antennas quantity	4
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	866 Mbit/s
Flash memory	16 MB
Internal memory	128 MB
Number of products included	1 pc(s)
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1 A
AC adapter output voltage	12 V
Power consumption (typical)	8.55 W
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Width	92 mm
Weight	197 g
