D-Link DAP-1320 User Manual

21D-Link DAP-1320 User Manual
Section 3 - Conguration
WPS Button
3. Press and hold the WPS button on your wireless router or access
point until the light starts blinking green and then release.
Allow up to two minutes for the WPS process to nish. When a
connection is successfully established, the LED on the device
should turn solid green.
Note: Refer to your router or access point’s user manual instructions
for the WPS process.
4. If your wireless device does not support WPS, click Select this
option if you want to set up your network manually as the
conguration method.
Click Next to continue.
5. Wait while your device scans for available Wi-Fi networks. You will
see a list of networks found. Select the Wi-Fi Network you wish
to use, click Select.
Note: If the network you would like to connect to isn’t listed, click
Back and select the manual option again to perform another scan.
Make sure you are in range of your wireless router.

D-Link DAP-1320 Specifications

Wireless Standards and Antennas

wireless standards	IEEE 802.11n, IEEE 802.11g
antenna type	2 Internal Antennas

Weight and Dimensions

dimensions	1.89” x 1.65” x 2.11” (4.8 x 4.19 x 5.36 cm)
weight	0.152 lb (68.94g)
