D-Link DAP-1522 User Manual

7 D-Link DAP-1522 Quick Install Guide
1. Make sure that a wired connection from your PC is made to one of the
LAN ports on the DAP-1522.
2. Make sure that the PC has an IP address of 192.168.0.xx and the subnet
is 255.255.255.0.
3. Open a web browser on your PC and type “
http://DLINKAP” to access
the web interface.
4. The default username is “
admin” and the password is blank.
5. Click on
Launch Wireless Setup Wizard, and follow the steps that
appear. Refer to the manual on the included CD for detailed information
on this setup.
6. Once you have setup the DAP-1522, move it to the location where you
wish to use it.
7. Plug the power adapter into the wall and into the back of the DAP-1522.
Plug the Ethernet cable between the device you wish to use and the
DAP-1522, and then power on the DAP-1522.
Manual Setup
Click Launch Wireless Setup Wizard

D-Link DAP-1522 Specifications

General

Maximum data transfer rate	1000 Mbit/s
Internal	No
Certification	Wi-Fi, FCC, IC
Security algorithms	WPA, WPA2
Connectivity LEDs	Yes
Compliance industry standards	IEEE 802.11n (draft 2.0), IEEE 802.11g, IEEE 802.3, IEEE 802.3u
Minimum system requirements	CD-ROM
Compatible operating systems	Windows Vista/XP SP2/2000 Mac OS X (v10.4)
Package weight	771.1 g

Weight and Dimensions

Weight	226.8 g
Dimensions (WxDxH)	111.8 x 144.8 x 33 mm
