D-Link DAP-1522 User Manual

8D-Link DAP-1522 Quick Install Guide
Note: If you are using AP mode, please see the manual for more information on AP
mode setup.
1. On your PC, open the Windows
®
menu.
Click on “Network”.
Note: Connect the DAP-1522 to the router or PC
with an Ethernet cable, and make sure to set up
your IP address to 192.168.0.xxx and subnet to
255.255.255.0 on your PC rst.
2. Click on the icon labeled “DAP-1522“.
3. You will be prompted to enter a PIN. The PIN is located on a label under
Windows Vista Setup

D-Link DAP-1522 Specifications

General

Maximum data transfer rate	1000 Mbit/s
Internal	No
Certification	Wi-Fi, FCC, IC
Security algorithms	WPA, WPA2
Connectivity LEDs	Yes
Compliance industry standards	IEEE 802.11n (draft 2.0), IEEE 802.11g, IEEE 802.3, IEEE 802.3u
Minimum system requirements	CD-ROM
Compatible operating systems	Windows Vista/XP SP2/2000 Mac OS X (v10.4)
Package weight	771.1 g

Weight and Dimensions

Weight	226.8 g
Dimensions (WxDxH)	111.8 x 144.8 x 33 mm
