D-Link DES-1005P User Manual

1
ABOUT THIS GUIDE
Congratulations on your purchase of the D-Link DES-1005P. This
device integrates 100Mbps Fast Ethernet and 10Mbps Ethernet
network capabilities in a highly flexible package. Port-1 on the switch
supports Power over Ethernet (PoE), meaning it will automatically
detect the presence of an IEEE 802.3af-compliant powered device (PD)
and provide power through the port. The switch provides up to 15.4 W
per PoE port and can be used to power WLAN access points, IP
phones, video cameras, and other PD devices. The Switch will
automatically detect the network appliance’s requirements, and will
supply the required power to each appliance accordingly.
Purpose
This manual will familiarize you with the DES-1005P and guide you
through the installation process.

D-Link DES-1005P Specifications

General

MAC address table	2000 entries
Store-and-forward	Yes
Maximum data transfer rate	0.2 Gbit/s
Supported data transfer rates	10/100 Mbit/s
10G support	No
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
Networking features	Fast Ethernet
Packet transfer speed	148800 pps
Switch type	Unmanaged
Switch layer	-
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports quantity	5
Power over Ethernet (PoE) ports quantity	1
Power consumption (typical)	1.8 W
Certification	RoHS, FCC, ICES-003, cUL
Product color	Black
LED indicators	Link, PoE
Mean time between failures (MTBF)	324616 h
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Depth	85 mm
Width	140 mm
Height	28 mm
