D-Link DES-1005P User Manual

5
UNPACKING AND INSTALLATION
Unpacking
Open the box and carefully unpack it. The box should contain the
following items:
 One DES-1005P
 One External Power Adapter
 Wall Mount Kit
 Four rubber feet
 Quick Installation Guide
If any item is found missing or damaged, please contact your local
reseller for replacement.
Setup
The setup of the DES-1005P can be performed using the following
steps:
 The power outlet should be within 1.82 meters (6 feet) of the
Switch.
 Visually inspect the DC power jack and make sure that it is fully
secured to the power adapter.
 Do not cover the ventilation holes on the sides of the Switch,
and make sure there is adequate ventilation around it.
 Do not place heavy objects on the switch.

D-Link DES-1005P Specifications

General

MAC address table	2000 entries
Store-and-forward	Yes
Maximum data transfer rate	0.2 Gbit/s
Supported data transfer rates	10/100 Mbit/s
10G support	No
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
Networking features	Fast Ethernet
Packet transfer speed	148800 pps
Switch type	Unmanaged
Switch layer	-
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports quantity	5
Power over Ethernet (PoE) ports quantity	1
Power consumption (typical)	1.8 W
Certification	RoHS, FCC, ICES-003, cUL
Product color	Black
LED indicators	Link, PoE
Mean time between failures (MTBF)	324616 h
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Depth	85 mm
Width	140 mm
Height	28 mm
