D-Link DES-1024D User Manual

ii
TABLE OF CONTENTS
About This Guide ......................................................... 1
PURPOSE ..........................................................................................1
TERMS/USAGE .................................................................................1
OVERVIEW OF THIS MANUAL.........................................................1
Introduction .................................................................. 2
FAST ETHERNET TECHNOLOGY.....................................................2
SWITCHING TECHNOLOGY .............................................................3
FEATURES ........................................................................................4
Unpacking and Setup.................................................... 5
UNPACKING .....................................................................................5
SETUP ...............................................................................................5
DESKTOP INSTALLATION................................................................5
RACK MOUNTING............................................................................6
Identifying External Components................................. 8
FRONT PANEL..................................................................................8
REAR PANEL....................................................................................9
Technical Specifications ............................................. 10
Technical Specifications ............................................. 11
Warranty and Registration.......................................... 12

D-Link DES-1024D Specifications

General

MAC address table	8000 entries
Store-and-forward	Yes
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u
Switch type	Unmanaged
Switch layer	L2
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports quantity	24
Safety	UL
Product color	Black
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Dimensions (WxDxH)	280 x 44 x 180 mm
Networking features	Fast Ethernet
Connectivity technology	Wired
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	1900 g
